Reducing dislocations in gallium arsenide on silicon templates

By posted on August 5, 2020 1:32PM

University of California Santa Barbara (UCSB) within the USA has been running to optimize gallium arsenide (GaAs) molecular beam epitaxy (MBE) on gallium phosphide on silicon (GaP/Si) [Daehwan Jung et al, J. Appl. Phys., vol122, p225703, 2017]. Normally, the increase of GaAs on Si makes use of off-axis substrates in efforts to avoid anti-section domains. On-axis silicon is favored for compatibility with CMOS processing foundries. The lattice mismatch between GaAs and Si is ~4%, main to dislocations.

The researchers controlled to lessen threading dislocation densities (TDDs) to 7.2×106/cm2, a factor of 40 decreases than for an unoptimized method. They comment: “We accept as true with that those exceptional GaAs buffer layers with low TDDs and clean surfaces will serve as flexible templates for high-performance Si-based optoelectronic gadgets, including lasers and photodetectors as well as a myriad of photonic included circuits crafted from those gadgets.”

The researchers used an industrial 300mm GaP/Si (001) template from NAsPIII/V GmbH. The expected unintentional miscut of the template become doubtlessly most effective zero.1-zero.2°. The silicon wafer turned into subjected to a special pre-epitaxial warmness treatment designed to terminate anti-section domain names in the 45nm GaP layer.

The wafer changed into split into small pieces and placed on molybdenum adapting plates within the Veeco MBE chamber. After oxide desorption, the increase commenced with 100nm GaAs at four hundred-550°C. The temperature became then raised to six hundred°C for 3μm GaAs layer increase.

Electron channeling evaluation imaging (ECCI) measurements gave a threading dislocation density (TDD) of ~2.8×108/cm2 averaged over a 1800μm2 vicinity on a reference unoptimized GaAs/GaP/Si sample, which became constant with outcomes from extra traditional plan-view transmission electron microscopy (TEM). ECCI lets in dislocation density checks over large areas, decreasing uncertainties. Root-mean-rectangular (RMS) roughness of the reference became 7.8nm, in keeping with atomic pressure microscopy (AFM) on 10μmx10μm fields.

Various optimizations were applied to the growth process: in-situ thermal cycle annealing, dislocation clear out layers and changing the increased temperature of the low-temperature GaAs layer.

The annealing consisted of 500°C low-temperature GaAs, 1.5μm high-temperature GaAs, 4x thermal cycling between seven hundred°C and 320°C, and 1.5μm extra excessive-temperature GaAs. ECCI measurements gave a TDD of 5.5×107/cm2. RMS roughness was four.8nm. The team believes that the dislocations are eliminated by using gliding and misfits fusing or annihilating.

A style of dislocation filter out layers was tested. The first-class worried 10 durations of 10nm indium gallium arsenide (In0.1Ga0.9As) and 10nm GaAs carried out after thermal cycle annealing, giving 7.2×106/cm2 TDD and a couple of.9nm RMS roughness. The 200nm filter turned into capped with 1.3μm GaAs. The InGaAs turned into applied at 500°C. Somewhat decrease TDDs of 1.2-1.4×106/cm2 have been accomplished with metal-natural chemical vapor deposition (MOCVD) on 4-6° offcut substrates. Also, better annealing temperatures may be reached in MOCVD chambers.
